  Phoenix Non Conveyorized Rotary Arm Automatic Pallet Wrapper - Cantilevered Frame


PRTL-2150A


Phoenix PRTL-2150A Automatic Rotary Arm

3 Year Unlimited Warranty
The Full Power of an Automatic Stretch Wrapper Without the use of Conveyors.
The PRTL-2150A provides fully automatic stretch wrapping without the use of conveyors. Either pallet jacks or Forklifts simply located the pallet on the floor in the wrapping area. The operator then yanks the pull cord to start the automatic wrapping cycle. Use with unstable or very heavy loads where production rates requires automatic capability. 14 RPM, Up to 30 Loads Per Hour, Unlimited Load Weight. If you are on a budget and you want to maximize your productivity, the PRTL-2150A is the most Affordable Answer to High Speed Automation.
Available in 3 mounting configurations Wall Mount, Floor Mount and Free Standing Gantry.
CheckedBIGGER - 52"x 52" MAX LOAD CAPACITY - THE LARGEST IN HIS CLASS!

Octagonal Table With 52" x 52" max pallet size (80" load diagonal) the rotary arm can easily wrap pratically anything you throw at him! The PRTL-A series provides the large wrapping capacity in its class!

This system is perfect for any wrapping application, excelling in particular at wrapping application that requires to wrap light or unstable loads or for speeds which would otherwise cause the load to topple due to high rotation speeds.
CheckedBUILT TO LAST - DESIGNED FOR MAXIMUM STRENGHT!

Octagonal Table Rugged all-structual steel construction reflects the durability of this machine. HSS tubing provides a strong and light-weight arm minimizing the driving forces required to rotate the arm.

Steel weldment of arm assembly is designed form maximum strenght while keeping the rotating weight to a minimum.
Learn more about our rotary arm design here

CheckedFASTER - 14 RPM, FASTEST WRAPPING SPEED IN HIS CLASS!

At 15 RPM the plpa-2150 is the fastest in his class! With 14 rpm stretch wrapping speed the PRTL-2150A is the fastest stretch wrapper in his class. Up to 30 pallets per hr. (based on load configuration and machine options), larger, variable speed drives control all motors for maximum flexibility, heavier, and faster wrapping than most competitive machines.
CheckedFLEXIBLE - PHOENIX OPERATOR INTERFACE CONTROL OFFERS OPTIONS AND FLEXIBILITY AS STANDARD!

More stretch wrapping controls and flexibility as standard
Control panel withAllen Bradley PLC with pushbutton and selector switches
Learn more here
Allen Bradley Power Flex Series variable frequency drive controls all motors on the machine. This ensures maximum performance including:
- Ultimate acceleration and deceleration control that effectively eliminates lurching starts and stops associated with motor starters that topple even typically stable loads.
- Eliminates the maintenance issues associated with the D.C. motor brushes.
- Digital readout allows for monitoring of the speed, amps, voltage, etc
- Alarm diagnostics; simplifying the troubleshooting process.
- Drive is internally protected and is totally enclosed thus eliminating the potential for shock and accidental short circuits.
Learn more about the Phoenix Operator Interface features here
CheckedSAFER - 3 STEP "EASY THREAD" FILM LOADING ENSURES MAXIMUM SAFETY

Stretch Film Savings Feature Re-loading the Film roll on any carriage is not an easy task with many machines. With our “Easy Thread” access design, we make it simple and safer. Simply unlatch and open the access door, pull film tail past open access door and close the door. It's that simple!
Learn more about the Film Carriage feature here
CheckedFILM SAVINGS - SEPARATE 1-9 TOP AND BOTTOM WRAP PROVIDES UP TO 15% FILM SAVINGS!

Stretch Film Savings Feature Separate 1-9 top and bottom wrap count provides up to 15% film savings. apply only the stretch film required at the top separately from the bottom compared to competitive models that applies a common amount to top-bottom regardless of need.
Separate up and down carriage speeds eliminates the time and wasted stretch film applied with competitor’s common speed control. (Up to 10% savings). Learn more about the wrapping control features here
CheckedCUT & WIPE - AUTOMATICALLY CUTS THE FILM AND APPLIES THE FILM TAIL TO THE LOAD!

Phoenix Automatic Cut And Wipe System The Phoenix PRTL-2150A Cut & Wipe System not only cuts (not tears) the film, but also attaches the film to the load by wiping the full web of film down to the load so it doesn't unravel, compared to many competitive models that simply allow the film to hang and drag at the end of the cycle. As the PRTL-2150A is a true automatic system the location of the pallet on the table is not critical (as with competitive models). This important part of an automatic cycle does not rely on timing and operator accuracy in loading the pallet on the table like competitors. Learn more about our cut & wipe system here
OVERVIEW OF THE PHOENIX PRTL-2150A PALLET STRETCH WRAPPER

  • Capacity
    • 50” x 50” Maximum load width size.



  • Stretch Film Saving features such as:
    • Separate 1-9 top and bottom wrap count provides up to 15% Savings. Apply only the stretch film required at the top separately from the bottom compared to competitive models that applies a common amount to top & bottom regardless of need.
    • Separate up and down carriage speeds eliminates the time and wasted stretch film applied with competitor’s common speed control. (Up to 10% Savings).
Learn more about the Features of our Pushbutton Control Panel

Why would you pay extra money with competitive models if you can have these feature
already included in the price at no extra cost?

  • Standard Superior Features
    • Unlimited Load Capacity
    • Variable Speed Drives control all motors for maximum flexibility.
    • Electronic stretch film tension control with Analog electronic Sensor provides the ultimate in feedback control.
    • PLC controller with Pushbutton Operator Interface offers unlimited flexibility.
    • Automatic Load Height sensing photoeye is mounted in the stretch film carriage with adjustable track.
    • 30 Loads Per Hour Production Rate. Higher production rates are available.
    • 14 RPM.
    • Pneumatic Controlled Cut & Wipe System.
    • Warranty period for this stretch wrapping system is 5 years.
      Guaranteed For Life
      Prestretch rollers with 245% prestretch ratio as standard.
      Please read our full terms and conditions here

  • “Best in Class” Safety features:
    • Film loading Safety Shut-off switch automatically shuts down power during stretch film loading by Operator.
    • Easy Film Loading carriage with double lock door control for guaranteed locking.
    • Mushroom Twist & Pull E-Stop Button.

  • Stretch Wrapping Options:
    • 30" Powered Pre-Stretch Film Carriage Upgrade
    • Extended Wrap Height - 96"
    • Extended Wrap Height - 102"
    • Many other options are available...
View all available options for this Stretch Wrapper




CONTROL PANEL
Phoenix PRTL-2150A Stretch Wrapper Pushbutton Control Panel
The PRTL controls features an Allen Bradley PLC with pushbutton and selector switches

FILM CARRIAGE
Phoenix PRTL-2150A Stretch Wrapper Easy Threading Prestretch Film Carriage
20" Easy Threading Powered Prestretch Film Carriage.

ROTARY ARM
Phoenix PRTL-2150A Stretch Wrapper Rotary Arm and Carriage Lift System
Dual Boom Rotary Arm and Carriage Lift System.

ROTARY COMMUTATOR
Phoenix PRTL-2150A Stretch Wrapper Rotary Commutator
Provides power required for carriage drives on rotating arm.


RING BEARING DRIVE
Phoenix PRTL-2150A Stretch Wrapper Rotary Commutator
Ring bearings are used on motor cranes, hydraulic excavators, foundry equipment, and army tanks due to their ability to withstand harsh environments while supporting large oversized structures.

CLAMP CUT AND WIPE
PRTL-2150A Clamp Cut and Brush
Pneumatic Controlled Cut & Wipe System automatically cuts the film and applies the film tail to the load.
