Phoenix Conveyorized Rotary Arm Automatic Pallet Wrapper - Gantry Frame |
|
Built to last. Designed specifically for High Speed 24/7 applications - Gantry Frame version
Overhead Rotary Arm Stretch Wrapper systems eliminate the need to rotate the pallet being stretch wrapped. Heavy or unstable loads are wrapped quickly and efficiently with this series of Stretch Wrapper. Commonly used in-line with the rest of the packaging line. Up to 60-80 loads Per Hour, 25 RPM Wrapping Speed, 4000 lbs Weight Capacity.
|
|
|
|
Overview of the Phoenix PRTA-2200 Pallet Stretch Wrapper:
|
|
| |
- Capacity
- 56” x 56” Maximum load size, (includes pallet 48"x40", zero overwrap).
|
|
| |
- Speed
- 25 RPM stretch wrapping speed. Fastest in its Class.
|
|
|
| |
- Stretch Film Saving features such as:
- Separate 1-9 top and bottom wrap count provides up to 15% Savings. Apply only the stretch film required at the top separately from the bottom compared to competitive models that applies a common amount to top & bottom regardless of need.
- Separate up and down carriage speeds eliminates the time and wasted stretch film applied with competitor’s common speed control. (Up to 10% Savings).
Learn more about the Features of our Keypad Control Panel
|
|
Why would you pay extra money with competitive models if you can have these feature
already included in the price at no extra cost? |
|
| |
- Standard Superior Features
- 4,000 lbs. weight capacity. (Optional heavier weight capacity).
- Heavy-duty over-head Gantry Style construction with 4-legs supporting the machine frame for solid machine support and trouble-free operation.
- Dual boom, all steel rotary arm construction with dual #40 chain carriage lift.
- Variable Speed Drives control all motors for maximum flexibility.
- Electronic stretch film tension control with Analog electronic Sensor provides the ultimate in feedback control.
- PLC controller with Touchscreen Operator Interface offers unlimited flexibility.
- Automatic Load Height sensing photoeye is mounted in the stretch film carriage with adjustable track.
- 45-60 Loads Per Hour Production Rate. Higher production rates are available.
- 25 rpm (higher speeds are available).
- 18" System Top of Rollers for conveyors.
- Pneumatic Controlled Cut & Wipe System.
- Warranty period for this stretch wrapping system is 5 years.
Guaranteed For Life Prestretch rollers with 245% prestretch ratio as standard.
Please read our full terms and conditions here
|
|
| |
- “Best in Class” Safety features:
- Film loading Safety Shut-off switch automatically shuts down power during stretch film loading by Operator.
- Easy Film Loading carriage with double lock door control for guaranteed locking.
- Mushroom Twist & Pull E-Stop Button.
|
|
| |
- Stretch Wrapping Options:
- 30" Prestretch Carriage for wider stretch film.
- 30 RPM High Speed Rotation.
- Phoenix Integral Top Sheet Dispenser For PRTA System
- Inline Top Sheet Dispenser System
- Thermo Bar Film Cutter Upgrade
- Low Film Alarm.
- Rotary Arm Extended for 92" Wrap Dia.
- Forklift Loading/Unloading Station (Photo-Eye)
- A.B. (Allen Bradley) Power Flex VFD's.
- Many other options are available...
View all available options for this Stretch Wrapper
|
|
|
|
| |
|
|
| Touchscreen Controls with Variable Speed Drive. |
|
|
|
| |
|
| 20" Easy Threading Powered Prestretch Film Carriage. |
|
|
|
| |
|
| Dual Boom Rotary Arm and Carriage Lift System. |
|
|
|
| |
|
| Ring bearings are used on motor cranes, hydraulic excavators, foundry equipment, and army tanks due to their ability to withstand harsh environments while supporting large oversized structures. |
|
|
|
| |
|
|
|
| Pneumatic Controlled Cut & Wipe System automatically cuts the film and applies the film tail to the load. |
|
|
|
| |
|
|
|
